Description

ABB 3BHB007211R0101 (XVC768AE101) is a dedicated SCA current measurement scaling module for ABB's medium-voltage drive system. Its core function is to accurately collect, scale, convert, and isolate transmit current signals, converting on-site large current signals into standard signals recognizable by the control system, ensuring precise and reliable current monitoring and closed-loop control.

This module adopts industrial-grade triple protection coating and electrical isolation design, which can withstand moisture, dust, and electromagnetic interference, and is suitable for harsh working conditions in power, metallurgy, and chemical industries. Standardized interfaces and compact layout support rapid installation and maintenance-free operation, providing a stable current signal processing link for ABB's drive and automation systems.

Features

• Model: 3BHB007211R0101 (XVC768AE101), Type: SCA Current Measurement Scaling Board
• Compatible Systems: ABB Medium Voltage Drive System, Industrial Automation Control System
• Core Functions: Current signal acquisition, high-precision scaling, electrical isolation and signal transmission
• Signal Accuracy: High-precision sampling and linear conversion, ensuring measurement and control accuracy
• Isolation Design: High-voltage electrical isolation, suppression of common-mode interference, protection of the rear-end control unit
• Environmental Adaptation: Three-proof coating, moisture-proof, dust-proof, corrosion-proof, suitable for harsh industrial environments
• Installation and Maintenance: Compact design, standard interfaces, easy installation, supports long-term stable operation

Technical Specifications
